THIS PRODUCT IS A RESULT OF 31 YEARS OF
DEDICATED SERVICE WITH THE OWNERS AND
OPERATORS OF THE MODEL 919 GRAIN TESTER.
|
CLICK HERE TO SEE ONE IN ACTION! |
|
The Digital Solution for any Model 919 (Elevator Type)
Moisture Meter with our Patented Technology.
FACTORY APPROVED AND FIELD PROVEN
SINCE 2003.
Pioneer in the Digital Conversion
of the Model 919 Grain Tester.
With
the rising costs of farming, the future of grain testing demands
faster and more accurate results. Since the Quantum 919 Digital
retrofit for the Model 919 was introduced in 2003, these demands
have been met. Benefits of the digital display and built-in calibration
check shall not only eliminate guesswork, eye strain and downtime,
You
May Never Have to Ship this Meter to be Calibrated... EVER.
A Bright Idea...
Just Got Brighter!!
If You Can See It, You Can Read It.
"THE GUESSWORK ELIMINATOR"
Error Free Test Results From Any Angle!
Accurately Measure
Wheat, Oats & Everything In Between.
Compatible with CGC & Custom Charts
for the 919/3.5" Cell
WHAT WE
DID
|
|
BEFORE |
AFTER |
After
reading numerous PAMI reports from 1979, manufacturers of the
Model 919 grain tester were made aware of "room for improvements" to help minimize
the operator's reading errors created by the drum dial and meter
movement assembly.
AS
MUCH AS .5% ERROR IS INTRODUCED EACH TIME A READING IS TAKEN.
|
In fall of 2003, the first factory approved breakthrough in the industry removed the needle
error and discontinued electronic parts with a digital reader
which later received
a patent.
After 10 years of successful conversions, the drum dial is finally
addressed and digitized for reading chart increments. The resulting
combination is a... well, WE CAN LET THE METER SPEAK FOR ITSELF. |
SOME OF
OUR WORK
|
|
Pictured
is an outdated Labtronics 919 tester with a 3" cell &
dump. Manufactured from the early 1970's, it has been rendered
obsolete because charts for the cell are no longer supported. |
After converting to the 3.5" cell & digital reader in
2006, this meter is ready for the 21st century! The calibration
is easy
to set
and eliminates the error in adjusting the needle's minimum point. |
WITH
60% OF READING ERROR REMOVED, A PROPER STANCE IS STILL
REQUIRED
FOR DETERMINING THE DRUM DIAL NUMBER.
|
|
Here
is a Halross 919 tester built when it had patents pending in
1955. The cell was already updated to keep the unit in service.
It was now time to help minimize the operating errors that PAMI referred to in their recommendations. |
With
a full digital conversion, the test results are bright, fast
& easy
to read
from any angle. The operator's reading errors & guesswork
associated with the analog system has been eliminated! Adjustments for Measuring
Accurately is a Breeze. |
DIGITAL
DRUM READER ELIMINATES THE ERRORS DUE TO PARALLAX.
THE
OPERATOR IS STILL IN CONTROL OF THE TESTING PROCESS.
|
|
This
Motomco 919 with 3" cell & dump, also made in the early
1970's, lost its charm in 1985 when charts for 3" were discontinued.
Instead of a new tester, the customer opted for a double conversion. |
The result, a user friendly tester that delivers the accuracy that you have come to expect
from your 919. Operating procedures are easier and faster to
perform with digital
precision
at your fingertips! |
A
"HANDS DOWN" SOLUTION FOR AN INHERIT PROBLEM HAS BEEN
SOLVED
WITHOUT HAVING TO REPLACE THE
ENTIRE UNIT WITH A COMPUTER MODEL!
COMPLETE COMPATIBILITY |
BUILDING
A SIMPLE SOLUTION |
With
very few modifications made to the Model 919 in over 65 years,
this digital system is designed to conform to virtually any 919
casting. Using
the existing mechanical components of your tester, the entire unit is cleaned,
inspected / repaired and refitted with our patented digital reader
& display. The operation of the meter's function is left
unaffected without any new procedures to learn. We can also convert
the 3" cell to 3.5" when its time.
Custom
made charts for use with the Model 919 as well as charts supplied
by the Canadian Grain Commission retain their compatibility as
well as new ones being developed for the existing 919 technology.
Regardless of the age, brand or condition of your 919, the QUANTUM
919 Digital
is ready to bring it into the 21st Century.
|
LIFETIME
WARRANTY ON OUR ELECTRONICS |
|
INTERNATIONAL STANDARDS |
|
Calibration
of the Model 919 is set to International Standards. Keeping your
919 calibrated to this standard is easy to perform with our built-in
reference point feature. Our meters are checked monthly with
the Canadian Grain Commission to ensure you receive a properly
tuned and calibrated unit. A unique number is given to each converted
meter as a calibration reference check for when you need one. |
|
CONVERSION PRICES (CAD) |
|
DMM1 Kit |
Digital Reader / Hardware
/ AC Adapter |
$250 |
DMM2 Kit |
Digital Drum Reader / Hardware
/ AC Adapter |
$400 |
3.5" Cell
Kit |
Cell & Dump Assembly
/ Book of Charts |
$200 |
Labor |
Installation / Calibration
/ Factory Maintenance & Repairs (Parts Extra) |
$250 |
ADDITIONAL OPTIONS & SERVICES
AVAILABLE |
|
|
